- Multi Entry Video Panel KVL-C302i/3i/4i/TC306i/8i [D1]
-
Main Functions
- [UPGRADE]
- Mutual call with residents
- Easy & simple installation
- Door Open by I-Button Key
(Dallas Chip) *optional
- Up to 1,300 numbers of
I-Button Key registration
- White LED for visitor recognition at night
- [UPGRADE]
Specifications
| Power | DC 15V ±1V |
|---|---|
| Power consumption | 0.5W (On stand by), 4.5W (Full load) |
| Horizontal Resolution | Over 420 TV Lines |
| Assurance Temperature | -20℃ ~ +50℃ |
| TV System | NTSC / PAL |
| Lens | F = 3.6mm, F : 1.6 |
| Camera Angle | Diagonal 81°(angle adjustable) |
| AGC Control | Auto |
| BLC | Auto |
| Body Material | METAL ( Zn, Al ) |
| Min. illumination | 0.1 Lux (LED On) |
| Mount type | Flush Mount |
| Dimension | 125(W) x 290(H) 48.4(D) mm |
| Button type | - KVL-C302i : Direct 2 push button type - KVL-C303i : Direct 3 push button type - KVL-C304i : Direct 4 push button type - KVL-TC306i : Direct 6 push button type - KVL-TC308i : Direct 8 push button type |
| Extension Panel | - KEL-303: Direct 3 push button type - KEL-306: Direct 6 push button type - KEL-309: Direct 9 push button type - KEL-312: Direct 12 push button type - KEL-T324: Direct 24 push button type |
